OVERVIEW

New Isuzu D-Max S-CAB combines power and technology. This popular workhorse has been upgraded and empowered with the development of technology, making it the ultimate choice.

INTERIOR DESIGN

ALWAYS READY TO GO AGAIN.

Multiple storage spaces
Rear 60:40 tip-up seats
Central Locking System

EXTERIOR DESIGN

FOR EVERY ROAD, EVERY LOAD.

FEATURES

THE NEW ISUZU D-MAX S-CAB. NOW BETTER THAN EVER.

Multi-Information Display (MID)

Co-driver sliding seat

High contrast and stylish instrument cluster

Variable speed Intermittent Wipers

High mount stop lamp

Rear parking sensor

Colours

Galena Gray Met

Titanium Silver Met

Splash White

SPECIFICATIONS

Model S-CAB 2WD HR S-CAB 2WD CBC HR
Type 4 Cylinder, Common Rail, VGT Intercooled Diesel 4 Cylinder, Common Rail, VGT Intercooled Diesel
Cubic Capacity (cc) 2499 2499
Engine Max Power 58 kW/78 hp @ 398 rad/s (3800 rpm) 58 kW/78 hp @ 398 rad/s (3800 rpm)
Engine Max Torque 176 Nm @ 157 - 251 rad/s (1500 - 2400 rpm) 176 Nm @ 157 - 251 rad/s (1500 - 2400 rpm)
Emission level BS 6 stage 2 BS 6 stage 2
Model S-CAB 2WD HR S-CAB 2WD CBC HR
No. of speeds 5 Speed 5 Speed
Shift Type Manual Manual
Model S-CAB 2WD HR S-CAB 2WD CBC HR
Brake Type Hydraulic Brake with large booster (26.67 cm) and LSPV Hydraulic Brake with large booster (26.67 cm) and LSPV
Front Brake Ventilated Disc with Twin Pot Caliper Ventilated Disc with Twin Pot Caliper
Rear Brake Drum Drum
Steering Typre Hydraulic Power Assist with Tilt Adjustment Hydraulic Power Assist with Tilt Adjustment
Model S-CAB 2WD HR S-CAB 2WD CBC HR
Overall Vehicle
(LxWxH) in mm
5200 x 1860 x 1780 5405 x 1860 x 1780
Wheelbase
in mm
3095 3095
Cargo Deck Inner
(LxWxH) in mm
1485 x 1530 x 465 1485 x 1530 x 465
Model S-CAB 2WD HR S-CAB 2WD CBC HR
Payload 995 kg 995 kg
GVW 2850 kg 2850 kg
Kerb Weight 1855 kg 1740 kg
Model S-CAB 2WD HR S-CAB 2WD CBC HR
Fuel Tank 55 litre 55 litre
DEF Tank 14.7 litre 14.7 litre
Seating capacity D+4 D+4
Model S-CAB 2WD HR S-CAB 2WD CBC HR
Front Double Wishbone, with Coil Springs & stabilizer Double Wishbone, with Coil Springs & stabilizer
Rear Semi-Elliptic Leaf Spring Semi-Elliptic Leaf Spring
Model S-CAB 2WD HR S-CAB 2WD CBC HR
Wheel Rim Size 16 x 6.5J-33 16 x 6.5J-33
Tyre Size 205R16C 205R16C
Tyre Type Radial Tubeless Radial Tubeless
 COMFORT AND CONVENIENCE
  • Power Steering with Tilt Adjustment
  • Air Conditioner with Heater
  • Dust & Pollen Filter
  • Seat-belt Height Adjuster
  • Inner & Outer Dash Noise Insulation
  • Advanced Electroluminiscent Multi Information Display console
  • ORVMs with Adjustment Retention
  • Roof Assist grip for Co-driver
 SAFETY AND SECURITY
  • Hydraulic Brake with large booster (26.67 cm) and LSPV
  • Ventilated Front Disc Brake with Twin Pot Caliper
  • Brake Override System
  • Chassis & Cabin with Crumple Zones
  • Cross Car Front Beam
  • Door Side Intrusion Beams
  • Collapsible Steering Column
  • Variable Intermittent Windshield Wiper
 UTILITY
  • 12V Mobile Charging Point
  • Retractable Cup and Coin holders on Dashboard
  • Door Trims with Bottle Holder and Pocket
  • Twin Glove Box
  • Centre armrest with storage space
  • Antenna
